   This still is made from a recycled, heavy gauge 55 Gallon Stainless Steel Food Grade Barrel.

Standard:

  • 2" Tri Clamp Fill Inlet with Cap

  • Thermometer

  • Open No Pressure Distilling System

  • 1" Drain Valve with Tri Clamp Connection

  • All Components are Pressure Tested for Leaks to 10 PSI

  • Pressure Relief Valve

  • Clamp on Removable Lid with EPDM Gasket

  • Your Choice: 6" Stainless Pot Still Column (like the still above) or 4" Copper  Pot Still Column (like the still below)

  • The 6" x 18" 304 SS  Stainless Column has a Removable Perforated Stainless Plate Above Which Copper May be Placed

  • Both Columns Come with a Clamp On 2" Diameter x 40" Long all Copper Shot Gun Condenser

  • 4"x 24" Copper Pot Still Column Comes with a removable Perforated stainless plate and Structured Copper Packing

  • All Welds are Sanitary Tig Welds on Stainless and Copper

  • No Ugly Solder or Brazing

  • Propane or Natural Gas Fired

  • 4" Tri Clamp Connection for Column

  • 1 Year Warranty on all Non Electrical Components

Price: $1,884.75 (including shipping within lower 48)

Options:

3" Commercial Thermometer in centered in the side of the boiler with a 1.5" Tri Clamp Port and Thermo Well. Price $70.00

Removable Copper Parrots Beak sized for this Still, with a 3/4" Drain Valve for first shots and 3/4" copper union (this Parrot is on the still at the bottom left of this page. Price $95.00

4" x 42" Copper Reflux Tower with Dephlegmator, adjustable temperature control and Copper Condenser. This column will produce from 140 to 180 proof, depending on the dephlegmator adjustment. All joints and seams are sanitary Tig welded.  This column is shown on the still in the pictures below left. The hose Barb connections for the cooling lines are on the back side so they cannot be seen in the photos.  We reinforce the lids of the stills that carry these columns, by ribbing them with stainless, as shown in the picture at the bottom left of this page. The price of this 55 gallon still with this column is $2,850.00 (including shipping within lower 48)

Heavy Duty Burner Stand like the one shown below. Price $254.00  This Burner Stand comes Standard With:

  • 210 K BTU Banjo Burner
  • 0 - 30 PSI Regulator
  • 6' of Hose
  • Built from heavy duty 1-1/4" Steel Tubing



If you have any questions or if you would like to order a still call 417-778-6100 or email paul@distillery-equipment.com  All major credit cards are accepted.
